Industrial Gate Valve Manufacturer

1.Fully compliant with API 600 and DIN standards for immediate industrial integration.
2.Fire-safe, metal-seated designs available in large & regular stock for critical safety applications.
3.Engineered for easy installation and maintenance-free operation with all items in stock & ready to ship.
4.Professional ex-stock supply serving chemical, refinery, and power industries globally.
5.Suited for corrosive, high-pressure, and extreme temperature environments with various types in ready stock.

Categories

Gate Valve

Sedelon® is a trusted industrial gate valve stockist maintaining a massive, regular ex-stock inventory of API 600, API 602, and DIN 3352 compliant gate valves for the global oil & gas, petrochemical, power generation, and marine sectors. Our ready stock covers forged steel gate valves, cast steel gate valves, stainless steel gate valves, and special alloy gate valves in materials including WCB, CF8M, Duplex (F51/F53), and Hastelloy – all available with manual, gear-operated, pneumatic, or electric actuated configurations. All items are in stock and ready to ship, ensuring fast global delivery to keep your project on schedule.

As a leading industrial gate valve stockist, Sedelon® maintains a large, regular ex-stock inventory of API 600, API 602, and DIN 3352 compliant gate valves – from compact 1/2″ forged gate valves to large-diameter 24″ cast steel gate valves. Our ready stock & fast delivery model provides immediate ex-stock supply across the full material spectrum: from standard WCB carbon steel gate valves to corrosion-resistant Duplex stainless steel and Hastelloy alloy gate valves. All items are in stock and ready to ship, ensuring the shortest lead times for your global projects.

Industrial Gate Valve Stockist: Technical Specifications & Ready-to-Ship Inventory

Gate Valve Type (Standards) Materials in Stock (ASTM) Pressure Rating (Class) Size Range (NPS) Availability Status
API 600 Cast Steel Gate WCB, LCB, WC6, WC9 Class 150 – 1500 2″ – 24″ Ready to Ship
API 602 Forged Steel Gate A105, LF2, F304, F316 Class 800 – 2500 1/2″ – 2″ Immediate Dispatch
Stainless Steel Gate Valve CF8, CF8M, CF3, CF3M Class 150 – 600 1/2″ – 12″ Large Regular Stock
DIN 3352 Standard Gate Cast Iron, Ductile Iron PN10, PN16, PN25 DN50 – DN600 Ex-stock Supply
Special Alloy (Monel/Duplex) 4A, 5A, Alloy 20, Monel Class 150 – 900 2″ – 8″ Stock Available

Engineering Features & Custom Solutions:

  • Material Versatility: In-stock industrial gate valves available in forged steel (A105, LF2), cast steel (WCB, WC6, WC9), stainless steel (CF8/304, CF8M/316), and specialty alloys (Hastelloy, Duplex F51/F53, Monel, Alloy 20) for corrosive, cryogenic, and high-temperature environments.
  • Full Standard Compliance: Fully compliant with API 600, API 602, API 603, and DIN 3352; available with fire-safe design per API 607 and fugitive emission control per ISO 15848-1.

  • Flexible Wedge & Seat Options: Choice of solid wedge, flexible wedge, or resilient seated disc designs; renewable or integral seat options for bubble-tight, zero-leakage gate valve performance.
  • Severe Service Applications: Pressure seal gate valves for high-pressure/high-temperature (HPHT) service; bellows sealed gate valves for toxic or hazardous fluid isolation; cryogenic gate valves for LNG and low temperature applications.
  • Operation & Connection: Manual handwheel, bevel gear, pneumatic actuator, or electric motor operated; supports flanged (RF/RTJ), butt weld (BW), socket weld (SW), or NPT threaded ends.
  • Industrial Utility: Specialized knife gate valves stocked for slurry, pulp, thick, abrasive, or viscous media applications in mining and wastewater treatment.
  • API 600: Gate valves standard for general use.
  • API 602: Standard for Forged Steel Gate valves.
  • API 603: Standard for Stainless Steel Gate valves.
  • ISO 15848-1:2006: Certification for fugitive emission and low leakage gate valves.

For pipelines requiring pigging, the internal cavity configuration of a gate valve is more critical than the sealing surfaces. The inclined geometry and internal steps of a wedge gate can obstruct pigs, while debris can become compacted between the sealing surfaces and leave indentations. A slab gate valve uses a single flat parallel gate with two sets of floating seats. When fully open, the flow passage has the same diameter as the pipeline, allowing pigs to pass directly through. This series is designed and manufactured in accordance with API 6D, covering 2″–48″ (DN50–DN1200), Class 150–2500. Valve body materials include WCB, LCC, CF8, CF8M, and A105. Each valve is pressure tested in accordance with API 598.

Standard-bonnet gate valves used on cryogenic LNG pipelines and buried underground pipelines can have the packing gland positioned too close to the cryogenic medium or pipeline wall. Heat transfer can cause the packing to freeze and crack, making this one of the most common failure modes of standard-bonnet cryogenic gate valves.

This series is designed and manufactured in accordance with BS 6364, covering NPS 2–48 and Class 150–900. It features low-temperature steel valve bodies, and every valve is pressure-tested in accordance with API 598.

Small-bore gate valves are often overlooked, yet pressure boundary integrity is critical in high-pressure service. Sedelon manufactures API 602 forged steel gate valves in NPS ½–2 and Class 150–600, providing a finer grain structure with reduced risk of porosity and shrinkage cavities compared with cast construction. End connections are available in RF flanged or butt-weld configurations. Body materials include A105, F304/F316, LF2, F11/F22, and F51/F53, and every valve is shell and seat tested in accordance with API 598.

Carbon steel gate valves have two operating limitations: above 425°C, cementite in the steel begins to graphitize, causing a continuous reduction in strength; under high-pressure hydrogen service, hydrogen atoms penetrate the steel matrix, resulting in hydrogen attack and cracking. Neither type of failure can be prevented simply by increasing the wall thickness; upgrading to chromium-molybdenum alloy steel is necessary. This series is designed and manufactured in accordance with API 600/API 602, with face-to-face dimensions, flange connections, and butt-weld ends complying with ANSI B16.10, ANSI B16.5, and ANSI B16.25, respectively. Sizes range from NPS 1/2–24, with pressure classes from Class 150–2500. Shell and seat leakage tests are performed in accordance with API 598, and the valves meet NACE MR0175 requirements for sour service.

The flanged end forged gate valve is designed for small-bore piping where quick replacement and reliable isolation are required. Manufactured to API 602 for NPS ½″–2″ and Class 150–600, it features bolted flange connections to ANSI B16.5, face-to-face dimensions to ANSI B16.10, and forged bodies in A105, F304/F316, LF2, F11/F22, or F51/F53. Each valve is shell- and seat-tested to API 598 before shipment.

Gate valves offer extremely low flow resistance when fully open, making them one of the most widely used shutoff valve types in refineries and pipeline systems. For large-diameter, medium- and low-pressure applications, cast steel bodies are more economical and easier to manufacture than forged steel bodies. However, cast steel valves present two typical engineering challenges: repeated external leakage caused by insufficient gasket recovery after temperature cycling, and gate jamming caused by pressure buildup in the body cavity after closure. This series is designed and manufactured in accordance with API 600. Face-to-face, flange, and butt-welding end dimensions comply with ANSI B16.10 / B16.5 / B16.25. The range covers NPS 2–24 and Class 150–900, with shell and sealing tests performed in accordance with API 598.

API 602 is the dedicated standard for small-bore forged steel valves, separate from API 600 which governs cast steel gate valves at larger sizes. Sedelon builds this API 602 series with bodies forged in one piece, NPS ½″–2″, Class 150–600, in socket weld, NPT, raised-face flanged and butt weld ends. Bodies come in A105, F304/F316, LF2, F11/F22 and F51/F53, and every valve is shell- and seat-tested to API 598.

This product is a large-size rising stem wedge gate valve designed and manufactured in accordance with API 600. Available in NPS 30 to NPS 36 and Class 150 to Class 300, it is suitable for high-flow isolation applications such as crude oil transmission pipelines, tank farm inlet and outlet lines, and large-diameter circulating water pipelines in power plants. The sealing surfaces are hardfaced with Stellite alloy for enhanced resistance to erosion in sand-containing media.

Our industrial valves are designed for optimal performance and reliability across a wide range of applications.

This DIN/EN-compliant gate valve features a rising stem, resilient wedge gate and ductile iron body with a soft-seated design. It is suitable for shut-off service in water supply, circulating water and general fluid pipelines. Face-to-face dimensions and flange interfaces strictly comply with European dimensional standards, allowing direct replacement in existing European-standard pipeline systems.

Flanged gate valves rely on flange bolting and gaskets for sealing, whereas butt-weld gate valves eliminate these external connections by being welded directly into the pipeline. Their ends are beveled in accordance with ASME B16.25 to provide permanent installation and enhance system integrity. These API 600 / ASME B16.34 gate valves are manufactured in sizes ranging from NPS 2–24, featuring bolted bonnets for Class 150–600 and pressure seal bonnets for Class 900–2500. Available in WCB, LCB, WC6/WC9, CF8/CF8M, and Monel materials, each valve undergoes shell and seat testing in accordance with API 598.

API 600 steel gate valves provide reliable isolation for high-temperature, high-pressure steam, oil, and natural gas service in refineries, pipelines, power plants, and petrochemical facilities. These valves are available in WCB, WC6/WC9, CF8/CF8M, and cryogenic LCB/LCC materials, covering a temperature range from −46°C to 570°C, and feature Trim 5 (13Cr/STELLITE), a flexible wedge gate, and an OS&Y rising stem design. Available in sizes NPS 2–24 and Class 150–1500, these valves are manufactured in accordance with API 600, individually tested per API 598, certified for fire-safe performance according to API 6FA, and supplied with EN 10204 3.1/3.2 documentation.

Carbon steel gate valves are among the most widely used isolation valves in water, oil, and steam pipelines. However, they are also frequently misapplied. In many installations, gate valves are operated partially open to regulate flow, causing high-velocity fluid to erode the gate and sealing surfaces. Over time, this can lead to deep grooves in the seating surfaces and prevent the valve from achieving tight shutoff.

This series is designed and manufactured in accordance with API 600, with face-to-face dimensions conforming to ANSI/ASME B16.10, flanged ends to ASME B16.5, and butt-welding ends to ASME B16.25. The product range covers NPS 2–24 and Class 150–2500. The valve body is manufactured from WCB carbon steel, and shell and seat leakage tests are performed in accordance with API 598.

Our industrial valves are designed for optimal performance and reliability across a wide range of applications.

In high-temperature service above 425°C, conventional carbon steel gate valves can experience creep deformation, external leakage caused by bolt stress relaxation, and thermal expansion that causes the gate to seize. High-temperature gate valves are specifically designed to withstand cyclic thermal loading in demanding high-temperature applications.

This series is manufactured in accordance with API 600, covering NPS 2–48 and Class 150–450. Valve bodies are manufactured from chromium-molybdenum steel, and every valve undergoes high-temperature pressure testing in accordance with API 598.

Why Choose Sedelon as Industrial Valves Manufacturer?

Sedelon is your reliable industrial valve manufacturer. We have a trusted supply network as well as we offer the latest production and assembly machinery. Here are the reasons why you should choose us as your industrial valve supplier.

Frequently Asked Questions

1、Material
2、After Sales
3、Design
4、Standard
5、Production capability
6、Others
Are the gate valves using non asbestos packing?
Yes, the packing we adopt is non asbestos packing.
What type of material can you supply for gate valves?
We can produce material of WCB, WC6, WC9, CF8, CF8M, CF3, CF3M, F304, F316, CN7M, LC1, LC2, LC3, etc., including WCB cast steel gate valves, A105 forged gate valves, CF8M stainless steel gate valves, and Duplex alloy gate valves for corrosive service.
Do you have cryogenic gate valves?
Yes, we have cryogenic gate valves. We can assist to operate cryogenic treatment and test if needed. Our cryogenic gate valves comply with API 600 and are available in LF2 and LF3 low-temperature carbon steel, as well as austenitic stainless steel.
Do you have PMI/Spectrometer to verify the chemical content of material?
Yes, we have portable PMI, our foundry has a Spectrometer too.
What is your payment term?
We prefer T/T. Generally 30% T/T down payment, 70% T/T balance payment before delivery.
What is the standard of package?
Standard seaworthy packing, valves in water-proof plastic bags, fixed in plywood case.
Can you submit ITP for valves production?
Yes, we can provide ITP after receiving the order.
Does your company have WPS and PQR document?
Yes, we have these documents.
Do you produce gate valves with wedge of flexible type or solid type?
We produce both flexible and solid wedge gate valves.
Do your gate valves have rising stem or non-rising stem?
We produce both types.
Is the seat of gate valve renewable or integral?
Both types are available, depending on material. Austenitic stainless steel gate valves can have integral seats per API standards.
What connection types can you supply for gate valves?
Butt weld, flange end, socket weld, NPT thread, etc.
What is a bellows sealed gate valve and when is it used?
A bellows sealed gate valve uses a metallic bellows instead of conventional stem packing to achieve zero fugitive emissions from the stem. It is used in applications involving toxic, hazardous, or environmentally sensitive fluids such as chlorine, ammonia, or hydrogen sulfide, where any stem leakage would be unacceptable. Sedelon® stocks bellows sealed gate valves in compliance with ISO 15848-1.
What is a slab gate valve and where is it used?
A slab gate valve (also called a through conduit gate valve) features a single-piece gate with a bore that aligns perfectly with the pipeline when open, creating a full, unobstructed flow path. This design allows pipeline inspection tools (PIGs) to pass through freely. Slab gate valves are used in oil and gas transmission pipelines where pigging operations are required.
Is the gate valve production and design certified per API 600?
Yes, our production and design adhere to API 600 standards. In addition to API 600, we also manufacture gate valves per API 602 (forged steel), API 603 (stainless steel), and DIN 3352 standards.
What is your painting procedure for valves?
We have a painting operation manual and follow standard procedures.
Is the gate valve a finished product or can it be customized?
Gate valves are produced according to standards, but we can customize based on technical requirements.
What are the certifications gotten by your company?
Sedelon® is certified by API 600, API 6D, API 607, API 6FA, API 624, CE, ISO 9001, ISO 45001, ISO 14001, ISO 15848-1, etc.
What is the difference between API 600 and API 602 gate valves?
API 600 covers bolted bonnet cast steel gate valves typically used in larger sizes (2″ and above) for general industrial and pipeline service. API 602 covers forged steel compact gate valves in smaller sizes (1/2″ to 2-1/2″) designed for high-pressure applications up to Class 2500. Sedelon® maintains ex-stock inventory of both API 600 and API 602 gate valves for immediate dispatch.
What size range and pressure classes are available in your gate valve stock?
Sedelon® ex-stock gate valves cover sizes from 1/2″ (DN15) to 24″ (DN600) and pressure classes from Class 150 to Class 2500 (ANSI/ASME), as well as DIN PN10 to PN40. For API 602 forged gate valves, we stock sizes from 1/2″ to 2-1/2″ in Class 800 to Class 2500. For API 600 cast steel gate valves, sizes from 2″ to 24″ in Class 150 to Class 1500 are available for immediate dispatch.
What is your production capacity per product line?
It varies based on size, pressure, and material. The highest production capacity is for carbon steel.
Can you supply gate valves from stock for corrosive or high-temperature environments?
Yes, we have various types of valves in ready stock specifically for severe services. Our ex-stock supply includes gate valves made from WCB, CF8M, Monel, Hastelloy, and Duplex Stainless Steel, capable of handling temperatures up to 752°F (500°C).
Do you have any MOQ limit for valve orders?
Yes, there is a limit for small sizes, but for large sizes, 1 piece is acceptable.
Do you provide tagging for all items?
Yes, we can provide tagging based on your requirements.
What is your main market?
Middle East, Southeast Asia, America, Africa, Russia, and Australia.
Do you have equipment and staff to perform NDT?
Yes, we have the necessary equipment and qualified staff.
